66KV Zinc-plated Polygon ສາຍສົ່ງໄຟຟ້າ ເສົາເຫຼັກ

ຂໍ້ມູນຈໍາເພາະ:

Products	66KV Zinc-plated Polygon Electric Transmission Line Steel Pole
Type	Suspension Pole , Tensile Pole , Strain Pole , Angle Pole , Dead-end Pole , etc
Voltage Grade	10 ~ 500KV
Height	7 ~ 30m ( 25FT ~ 90FT).
Shape	Conical, Round, Polygonal (Octagonal, Dodecagonal, Hexadecagonal, etc),Tubular, Tapered
Material	Hot Roll Steel Q235, Q345, Q420, Q460, ASTM A527 A36, GR50, GR65 and others equivalent steel material
Wall thickness	2 ~ 6mm
Once Forming	16m Once forming without joint
Welding	Welding complies with AWS D1.1 standard. CO2 welding or submerged arc auto methods No fissure, scar, overlap, layer or other defects Internal and external welding makes the pole more beautiful in shape If customers need any other requirements of welding, we also can make adjustment ad your request
Joint	Joint with insert mode, flange mode.
Base plate	Base plate is square/round/Polygon with slotted holes for anchor bolt and dimension as per client’s requirement.
Galvanization	Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123.
Painting	According to clients' request
Life Period	More than 25 years, it is according to installing environment
Export Experiences	Philippines , Malaysia , Pakistan , Russia , UK , Australia , Ghana , Sierra Leone , Bangladesh , Maxico , Nigeria , Angola , Tanzania , Slovakia , New Zealand , Republic of the Congo , etc,
Advantages	Low Overall Cost Easy Installation and Maintenance Weather Resistance Anti-corrosion ODM & OEM are available Capable to Handle Volume Orders Provide Professional Design by Our Experienced R&D Engineers Short Construction Cycle Less Land Occupation

ລາຍລະອຽດ:

ເສົາໄຟຟ້າ Galvanized Steel Utility Poles ມີບົດບາດສໍາຄັນໃນອຸດສາຫະກໍາສາຍສົ່ງແລະຈໍາຫນ່າຍໄຟຟ້າແລະອຸດສາຫະກໍາໂທລະຄົມນາຄົມ. ເພື່ອຕອບສະຫນອງຄວາມຕ້ອງການທີ່ສູງຂຶ້ນສໍາລັບເສົາໄຟຟ້າ, ບໍລິສັດຂອງພວກເຮົາອອກແບບແລະຜະລິດເສົາເຫຼັກຫຼາຍຊະນິດສໍາລັບລະບົບສາຍສົ່ງແລະຈໍາຫນ່າຍໄຟຟ້າ.

ເປັນທາງເລືອກສໍາລັບເສົາໄມ້ແລະຊີມັງແບບດັ້ງເດີມ, ເສົາເຫຼັກກ້າທີ່ແຊ່ນ້ໍາຮ້ອນຂອງພວກເຮົາສາມາດໄດ້ຮັບການນໍາໃຊ້ເພື່ອຮັບຜິດຊອບຕົວນໍາແລະອຸປະກອນການແຈກຢາຍໄຟຟ້າ, ອຸປະກອນສົ່ງໄຟຟ້າ, ສາຍ, ແລະອື່ນໆ.
